Shaker Table

Zhengzhou Sinolion Machinery Co., Ltd. is one of the most credible manufacturers and suppliers of shaker table in China. Please feel free to buy high quality shaker table for sale here from our factory. Good service and reasonable price are available.

Shaker table is belonging to Gravity separation equipment, which is developed from the spiral chute, it becomes a class because of their character unsymmetrical reciprocating movement. This machine is applied to the separation of the particle size 2-0.0037 mm sand ore or slime ore of Gold, Tungsten, Tin, Titanium, Iron, Chrome, Manganese, and so on ferrous, Non-ferrous, precious metals etc. Separation of the particle size of 4-0.037mm’s pyretic. If change the riffles will separate tailing coal and slime coal, mozanite, rutile and so on non-metals and separation of those has enough density differences materials and reasonable density compound mixing materials.

Beneficiation process of shaker table is carried out on the tilt table with riffle, the minerals are sent by the feed launder on the bed superior angle, simultaneously, it supplies horizontally the washing water from the feed water launder. Under the effect of gravity, crosswise running water momentum, inertia and friction force produced by the bed reciprocating asymmetrical movement, minerals are stratified by weight and size, and make the longitudinal motion along the bed and transversal motion along the tilt bed. Therefore, the proportion and the granularity different minerals fan out along the respective heading from feeding to discharging, discharged separately from the different areas of concentrate side and tailing side, and then divided into the concentrates, middlings and Tailings. The obvious advantage of 6-s shaker table is its high ratio of accurate of separation which can eventually get the concentration,middling and tails simultaneously acquire many final products. The machine is high enrichment ratio, high efficiency of beneficiation, easy operation and convenient stroke adjustment. Changing the horizontal slope and stroke length.

working principle

The separation process of the 6-s shaker table is under the co-action of the deck shaking and horizontally flushing water, The riffle is vertical to be perpendicular with the water flow, the water flow flush horizontally over the slots of the riffle one by one come into being the eddy current,and the co-action of the eddy current and table shaking to make the sand ore layering because of their different density,the heavy one layer the next while the light one layer up. The light one will suffer heavier flush and heavy one suffer light flush,therefore the light one horizontally move more fast than the heavy one. This process is called parsing layer.

technical parameters:
