Municipal Solid Waste Sorting Plant
Zhengzhou Sinolion Machinery Co., Ltd. is one of the most credible manufacturers and suppliers of municipal solid waste sorting plant in China. Please feel free to buy high quality municipal solid waste sorting plant for sale here from our factory. Good service and reasonable price are available.
The necessity of garbage sorting:
The municipal solid waste(MSW) varies in different cities at different times. Generally, it consists of municipal household refuse, construction waste, ordinary industrial solid waste, and hazardous solid waste, etc. Owing to the complex types of municipal solid waste, it is very hard to treat them together. Meanwhile, most of the wastes are actually recyclable and holding large values potentially. Therefore, the municipal solid waste sorting machine which can get various wastes sorted according to the materials and future values has been turned out to be very useful.
A respectively complete waste sorting machine is consisted of the main parts like plate feeder, uniform material spreader, bag breaker, sealed belt conveyor, rotating screen machine, comprehensive winnowing machine, manual sorting platform, gravity separator, hydraulic packing machine, hydraulic metal presser, and spraying deodorization tower, etc.
The municipal solid waste sorting machine precise waste sorting system and has a strong capacity of sorting as many as 400 tons of wastes for one production line. Our waste separation machine can separate the various wastes clearly according to their volumes, materials, natures and future usages, etc. It cannot only be used for treating municipal solid waste but also used for mining waste sorting.
Hot Tags: municipal solid waste sorting plant, China, manufacturers, suppliers, factory, price, for sale, Rock Trommel Screen, Paper Baling Machine, MSW Sorting Plant, Garbage Recycling Drum Screen, Household Solid Waste Management, Waste Paper Press Baler
|
Model |
Drum size(m) |
Drum inclination (°) |
Drum speed (r/min) |
Mesh size(mm) |
Max feeding size(mm) |
capacity(m³/h) |
Motor power (kw) |
|
GTS820 |
Φ0.8×2 |
6-10 |
32 |
2-20 |
Mesh size×2.5 |
7-30 |
3 |
|
GTS830 |
Φ0.83 |
6-10 |
32 |
2-20 |
Mesh size×2.5 |
8-50 |
3 |
|
GTS1020 |
Φ1×2 |
6-10 |
25 |
2-20 |
Mesh size×2.5 |
10-60 |
4 |
|
GTS1030 |
Φ1×3 |
6-10 |
25 |
2-20 |
Mesh size×2.5 |
11-80 |
4 |
|
GTS1230 |
Φ1.2×2 |
6-10 |
20 |
2-20 |
Mesh size×2.5 |
12-100 |
5.5 |
|
GTS1240 |
Φ1.2×4 |
6-10 |
20 |
2-20 |
Mesh size×2.5 |
14-120 |
5.5 |
|
GTS1530 |
Φ1.5×3 |
6-10 |
17 |
2-20 |
Mesh size×2.5 |
16-120 |
5.5 |
|
GTS1540 |
Φ1.5×4 |
6-10 |
17 |
2-20 |
Mesh size×2.5 |
18-150 |
7.5 |
|
GTS1550 |
Φ1.5×5 |
6-10 |
17 |
2-20 |
Mesh size×2.5 |
20-180 |
11 |
|
GTS1560 |
Φ1.5×6 |
6-10 |
17 |
2-20 |
Mesh size×2.5 |
22-200 |
11 |
|
GTS1850 |
Φ1.8×5 |
6-10 |
14 |
2-20 |
Mesh size×2.5 |
24-220 |
15 |
|
GTS1860 |
Φ1.8×6 |
6-10 |
14 |
2-20 |
Mesh size×2.5 |
26-240 |
15 |
|
GTS2050 |
Φ2×5 |
6-10 |
12 |
2-20 |
Mesh size×2.5 |
50-600 |
22 |
|
GTS2080 |
Φ2×8 |
6-10 |
12 |
2-20 |
Mesh size×2.5 |
80-700 |
22 |
|
GTS2260 |
Φ2.2×6 |
6-10 |
10 |
2-20 |
Mesh size×2.5 |
100-800 |
30 |
|
GTS2280 |
Φ2.2×8 |
6-10 |
10 |
2-20 |
Mesh size×2.5 |
120-850 |
30 |
