Gold Trommel Washing Plant

Zhengzhou Sinolion Machinery Co., Ltd. is one of the most credible manufacturers and suppliers of gold trommel washing plant in China. Please feel free to buy high quality gold trommel washing plant for sale here from our factory. Good service and reasonable price are available.







Our gold trommel washing plant is a professional gold mining equipment that can be moved on land. It has the characteristics of compact structure, strong integrity, light weight, large processing capacity, simple operation, reliable work, convenient maintenance, and convenient operation.



The main structure of the gold trommel washing plant is the transmission part, the hopper, the screening trommel, the discharge port. Raw materials enter the screen cylinder through the hopper, and the rotating screen cylinder drives the raw materials. The screen mesh is designed with holes of uniform specifications to achieve the effect of separating materials. Equipped with a deceleration system, the screening trommel rotates at a certain speed, the material is separated from top to bottom through the screening trommel, and the fine material is discharged from the bottom of the screening cylinder to the discharge port. The large material is discharged from the tail of the trommel screen.





It can be loaded by excavator or forklift, and the hopper is equipped with a grille, which can screen out large-sized stones and avoid entering the drum to damage the screen. A water pipe is designed at the hopper, which can be connected to a water pump to wash the material during the feeding process, and the mixed soil can be washed away, which is more conducive to screening. The hopper part is designed with an operation platform, on which people can check the feeding situation and screening situation.



The screen mesh of the gold trommel washing plant is a double-layer design, and the outside is a layer of manganese wire braided mesh. The aperture of the conventional screen mesh is designed to be 5mm, which can be designed according to specific needs. The inside is a layer of round steel mesh. The materials entering the trommel are first It will pass through the round steel screen, which can withstand the impact of stones and protect the outer layer of manganese wire weaving. The gold trommel washing plant is designed with two outlets, which are located on both sides of the machine, so that the fine materials are discharged from the outlets, and the large materials are discharged from the tail of the trommel. The tail can also be equipped with a conveyor to transport large stones to a distant place to prevent accumulation near the trommel screen and affect work.



And there is also a horizontal water spray pipe designed on one side of the trommel. There are many small holes on the water pipe, which can spray water on the screen during the working process of the drum sieve, and can wash the material and the screen to prevent the screen from clogged.



The fine material is discharged from the discharge port, and then can be connected to the gold chute to collect gold. The gold chute is designed with high-quality gold panning grass, which can effectively capture the passing gold. During the working process, the gold panning grass can be fixed for a period of time Cleaning is carried out and the collected gold is selected.





Advantage:



① This is a very economical and feasible option, very suitable for gold ore washing plants that process small batches to large batches.



② The aperture of the screen can be customized according to the needs to ensure the complete separation of fine materials.



③ Designed with end-user flexibility, the screen can be replaced.



④ Double-layer screen strengthens the screening process.



⑤ The trommel screen has high efficiency and a large capacity to process materials of different volumes.



⑥ High-quality screen design and long service life.





If you want a complete gold mining production line to improve the recovery efficiency of gold, we can also provide supporting equipment, such as centrifugal concentrators, shaking tables, amalgamators, mercury distiller, gold melting furnaces, etc., through which continuous processing to form a complete set of gold panning production line, from initial gold selection to smelting into gold bars.



Sinolion gold equipment provider, professional gold trommel design service, gold trommel for sale!



These information helps our engineer to select the right machine for you, basic: feed material particle size, density, feed solids capacity, moisture, clay. What’s more, know your requirements such as the type of screen media, protective safety covers, etc.



Our service:

1. Before sale

Be a good customer’s adviser and assistant, let the user’s every investment get rich returns.

(1) selection of equipment model.

(2) design and manufacture products according to customers’ special requirements.

(3) training technical personnel for customers.



2. Sale

Respect customers; Give customers rest assured, a relaxed, a surprise; Committed to improving the overall value of customers.

(1) product acceptance.

(2) assist the client to draw up the construction plan.



3. After-sale

(1) assign special after-sales service personnel to guide the installation and debugging of customers on-site.

(2) equipment installation and debugging.

(3) on-site training of operators.



Delivery to Colombia:
