Our ball mill was shipped to Turkey, where the customer used it to process gold ore.
As the core model of small and medium-sized grinding equipment, the parameter design of the 900×1800 ball mill directly affects production efficiency and product quality. The following are the key technical parameters of this model:
1. Cylinder specifications: 900×1800 mm, taking into account both processing capacity and equipment compactness, suitable for small and medium-sized production lines.
2. Speed range: 38-41.6 rpm, which can be flexibly adjusted according to material characteristics to ensure grinding uniformity.
3. Motor power: 15-18.5 kW, balancing energy consumption and production capacity to reduce operating costs.
4. Processing capacity: 0.4-2 tons/hour, suitable for wet or dry grinding of fine to medium-grained minerals such as gold ore and iron ore.
5. Ball loading: 1.6-4.8 tons, using high chromium alloy steel balls to improve wear resistance and impact efficiency.
6. Dimensions and weight: The machine is approximately 4.75×2.3×2.25 meters in size and weighs 8.6 tons, which is convenient for transportation and on-site installation.
Application fields and advantages:
Due to its versatility, this ball mill can be widely used in the following scenarios:
Precious metal beneficiation: especially suitable for wet grinding of fine-grained minerals such as gold and tin ores to improve metal recovery rate.
Building materials production: used for grinding cement clinker, limestone, gypsum and other materials, helping Turkey's infrastructure material supply.
Environmental recycling: processing tailings and industrial waste to achieve efficient resource reuse, in line with the global sustainable development trend.
Technical highlights:
Energy-saving design: using double-row spherical roller bearings to reduce friction energy consumption by 20%-30%.
Structural optimization: overflow type discharge design to improve grinding fineness and processing capacity.
Intelligent control: supports precise adjustment of speed and feed concentration to meet complex working conditions.
Zhengzhou Sinolion Machinery Co., Ltd, specialize in the production and sales of mineral processing equipment, provide a full set of equipment solutions as well as engineer installation services, come and contact us for a quote!
